Tag: CAT 374

Caterpillar has launched three new Next Generation large excavators. When it comes to heavy-duty excavators, one of the most popular models on the market is the excavators CAT 374. Caterpillar’s new 374 weighs 71.7 tonnes and is powered by a 485hp Cat C15 engine. It has a maximum digging depth of 8.57m, a maximum reach at ground level of 13.16m and a maximum loading height of 8.43m.

Standard equipment on all machines includes Cat Payload (on-the-go bucket weighing), Cat Grade with 2D visual guidance, Lift Assist (monitors machine stability), E-Fence (prevents the excavator from moving outside operator-defined points), rear and side-view cameras (360-degree optional), Smart Mode (matches engine and hydraulic power to workload, saving fuel), a 10-inch touchscreen display in the cab and programmable joysticks. Maintenance wise, filter life has been doubled, access points moved lower to the ground, and service intervals increased.

Features of Excavator CAT 374

PERFORMANCE

• The C15 ACERT™ engine meets EPA Tier 2 US/Stage II EU or Tier 3/Stage IIIA equivalent emission standards.
• Exclusive Cat® Adaptive Control System (ACS) valves allow the machine to consume up to 28%* less fuel than the standard 374D L, while delivering the same high production rates.
• Automatic engine speed control lowers rpm based on load to reduce fuel consumption.
• Power mode helps you more actively manage fuel consumption.

CAT CONNECT TECHNOLOGY

Cat Connect technology solutions increase production, minimize operating costs and optimize return on investment by offering LINK, GRADE and DETECT technologies.

• Cat Production Measurement brings load weights into the cab so you can work more productively and deliver accurate loads with confidence.
• VisionLink® provides wireless access to machine operating data such as location, hours, idle time, fuel usage, productivity and diagnostic codes to optimize performance.

Cat Grade Control and AccuGrade™ provide real-time cutting and charging information to assist you in achieving grades and slopes more quickly and accurately.

MAINTENANCE

Routine maintenance items such as lube points and fluid taps are easily accessible at ground level.

• Side-by-side cooling systems allow for easy cleaning.
• Multiple S∙O∙S∙SM ports and pressure diagnostic taps help prevent maintenance downtime.

COMFORT

• The cab is more comfortable and 3 dB(A) quieter than the 374D L.
• Console and armrest -Joysticks are adjustable. Seats are adjustable and have air suspension and heated and cooled options.
• LCD monitor is easy to navigate and can be programmed in 44 languages.

VERSATILITY

• Quick and easy dismantling with scissors or Cat multi-processor.
• Quarry work is no problem with custom-made Cat buckets and hammers.
• A Cat coupler lets you swap between attachments in seconds without leaving the cab.
• Tool-control options recall pressure and flow for up to 20 tools to increase uptime.

DURABILITY

• Chamber and wand are built for long service.
• Structure -box parts with multi-plate fabrication, castings, and forgings are used in high-pressure areas. Track shoes, links, rollers, idlers and final drives are made with high tensile strength steel.
• Improved track passage between pins and washers increases undercarriage life and reduces noise.

SAFETY

• Smart fuel fills the engine quickly from an external fuel source, automatically stops when the fuel tank is full or the fuel source is empty, eliminating guess work and premature pump wear.
• Rear and side view cameras improve visibility to help make operators more effective and efficient.

Large serrated steps, extended hand and guard rails, and non-slip coatings will help you get in and around the machine.
